NATV 8 PP Support rollers (yoke-type track rollers) with flange rings and relubrication feature
NATV 8 PP Support rollers (yoke-type track rollers) with flange rings and relubrication feature detail Specifications :
Material : 52100 Chrome Steel
Construction : Single row
Seal type : seals on both sides
Limiting Speed : 2500 rpm
Weight : 0.042 kg
Main Dimensions :
Bore diameter (d) : 8 mm
Outside diameter flange ring (d2) : 19 mm
Outer diameter (D) : 24 mm
Width inner ring (B) : 15 mm
Width outer ring (C) : 14 mm
Dynamic load ratings (Co) : 7.80 KN
Static load ratings (Cor) : 11.40 KN
